ENGWE L20 3.0 Boost
ENGWE L20 3.0 Boost
Engwe L20 3.0 Boost
Power, Comfort and Range in a Compact Design
The Engwe L20 3.0 Boost is designed for riders who want more power, more comfort, and more freedom in their daily journeys. Fully compliant with UK/EU regulations (250W rated motor), it also includes a Boost Mode delivering up to 75Nm of torque, giving you the extra push needed for steep hills and heavy loads.
With its step-through frame, 20-inch anti-puncture tyres, and full suspension system, the L20 3.0 Boost provides a stable, smooth ride across both city streets and countryside paths. Combined with its removable 48V 13.5Ah battery offering up to 135km range, this e-bike is practical, powerful, and versatile.
Key Features
- EU/UK Legal – 250W motor with up to 75Nm torque in Boost Mode
- 48V 13.5Ah Battery – removable 648Wh capacity with BMS protection
- Fast Charging – 8A charger delivers full charge in approximately 2 hours
- Long Range – up to 135km per charge depending on assist level
- 20” x 3.0” Anti-Puncture Tyres – ideal for mixed terrains
- Hydraulic Disc Brakes – dual 180mm rotors for reliable stopping power
- Full Suspension – front hydraulic fork and rear spring for comfort
- 3.5” Colour Display – Bluetooth enabled, with Engwe App integration
- Integrated Lighting – 30 lux front light with horn, smart rear brake light
- Shimano 7-Speed Gears – smooth and efficient shifting
- Foldable Frame – compact for storage and transport
Specifications
General
- Model: Engwe L20 3.0 Boost (EU/UK version)
- Certification: CE / EN15194 compliant
- Maximum Load: 150kg
- Recommended Rider Height: 155–190cm
- Folding: Yes
Motor & Drive
- Rated Power: 250W (UK/EU legal limit)
- Boost Torque: Up to 75Nm
- Assist Levels: 5 PAS levels with torque sensor
- Drivetrain: Shimano Tourney 7-speed, 14–28T cassette
Battery & Range
- Battery: 48V 13.5Ah (648Wh), removable
- Cells: 21700 with integrated Battery Management System
- Charger: 54.6V 8A fast charger (~2h full charge)
-
Range (tested):
- PAS 1: up to 120km
- PAS 3: up to 100km
- PAS 5: up to 85kM
Frame & Suspension
- Frame: 6061 aluminium alloy, step-through design
- Front Suspension: Hydraulic fork, adjustable with lockout
- Rear Suspension: 30mm spring travel
Wheels & Tires
- Wheel Size: 20” x 3.0”
- Features: Anti-puncture layer, all-terrain hybrid design
- Rims: Double-wall aluminium, 36H
Brakes & Safety
- Brakes: Hydraulic disc brakes, 180mm front and rear rotors
- Lighting: 30 lux front headlight with integrated horn, automatic rear brake light
Cockpit & Comfort
- Display: 3.5” colour LED with Bluetooth, Engwe app integration
- Handlebars: 680mm swept-back ergonomic design
- Saddle: Comfort-focused, height adjustable (82–102cm)
- Seatpost: Quick-release clamp
Waterproof Ratings
- Wiring: IPX7
- Display and Lights: IPX6
- Motor and Controller: IPX5
- Battery Box: IPX4
Weight & Dimensions
- Net Weight: 33.2kg
- Gross Weight: 42kg
- Dimensions (unfolded): 168cm (L) x 110cm (H)
- Folded Dimensions: 100cm x 51cm x 75cm
- Standover Height: 38cm
In the Box
- Engwe L20 3.0 Boost E-bike
- 48V 13.5Ah battery
- 54.6V 8A charger
- Pedals
- Front and rear mudguards
- Rear rack
- Kickstand
- Assembly tools
- User manual
